3263 - Angle Flange Gasket

  • Black nitrile standard. 60 durometer. Temp range -20°F to 170°F.
  • Red silicone optional. 50 durometer. Temp range -65°F to 450°F.
  • Nitrile material is conductive.
  • One gasket per joint.
In stock
SKU
3263
Technical Data Sheet:
Part Number Diameter DescriptionPriceQtyTotal
3263-0300-000005 3 in. 3" Angle Flange Silicone Gasket$5.29
3263-0300-000000 3 in. 3" Angle Flange Nitrile Gasket$3.46
3263-0400-000000 4 in. 4" Angle Flange Nitrile Gasket$4.64
3263-0400-000005 4 in. 4" Angle Flange Silicone Gasket$7.13
3263-0500-000005 5 in. 5" Angle Flange Silicone Gasket$8.86
3263-0500-000000 5 in. 5" Angle Flange Nitrile Gasket$5.83
3263-0600-000005 6 in. 6" Angle Flange Silicone Gasket$10.91
3263-0600-000000 6 in. 6" Angle Flange Nitrile Gasket$7.34
3263-0700-000005 7 in. 7" Angle Flange Silicone Gasket$15.88
3263-0700-000000 7 in. 7" Angle Flange Nitrile Gasket$10.48
3263-0800-000005 8 in. 8" Angle Flange Silicone Gasket$17.06
3263-0800-000000 8 in. 8" Angle Flange Nitrile Gasket$11.45
3263-0900-000005 9 in. 9" Angle Flange Silicone Gasket$18.90
3263-0900-000000 9 in. 9" Angle Flange Nitrile Gasket$12.53
3263-1000-000005 10 in. 10" Angle Flange Silicone Gasket$26.89
3263-1000-000000 10 in. 10" Angle Flange Nitrile Gasket$17.93
3263-1100-000005 11 in. 11" Angle Flange Silicone Gasket$29.38
3263-1100-000000 11 in. 11" Angle Flange Nitrile Gasket$19.44
3263-1200-000000 12 in. 12" Angle Flange Nitrile Gasket$20.74
3263-1200-000005 12 in. 12" Angle Flange Silicone Gasket$31.10
3263-1300-000005 13 in. 13" Angle Flange Silicone Gasket$36.83
3263-1300-000000 13 in. 13" Angle Flange Nitrile Gasket$24.52
3263-1400-000005 14 in. 14" Angle Flange Silicone Gasket$38.77
3263-1400-000000 14 in. 14" Angle Flange Nitrile Gasket$25.81
3263-1500-000005 15 in. 15" Angle Flange Silicone Gasket$54.32
3263-1500-000000 15 in. 15" Angle Flange Nitrile Gasket$36.18
3263-1600-000005 16 in. 16" Angle Flange Silicone Gasket$57.02
3263-1600-000000 16 in. 16" Angle Flange Nitrile Gasket$38.02
3263-1700-000000 17 in. 17" Angle Flange Nitrile Gasket$40.07
3263-1700-000005 17 in. 17" Angle Flange Silicone Gasket$60.16
3263-1800-000005 18 in. 18" Angle Flange Silicone Gasket$64.80
3263-1800-000000 18 in. 18" Angle Flange Nitrile Gasket$43.20
3263-1900-000005 19 in. 19" Angle Flange Silicone Gasket$67.61
3263-1900-000000 19 in. 19" Angle Flange Nitrile Gasket$45.04
3263-2000-000005 20 in. 20" Angle Flange Silicone Gasket$70.31
3263-2000-000000 20 in. 20" Angle Flange Nitrile Gasket$46.87
3263-2100-000005 21 in. 21" Angle Flange Silicone Gasket$107.24
3263-2100-000000 21 in. 21" Angle Flange Nitrile Gasket$71.50
3263-2200-000005 22 in. 22" Angle Flange Silicone Gasket$111.56
3263-2200-000000 22 in. 22" Angle Flange Nitrile Gasket$74.41
3263-2300-000005 23 in. 23" Angle Flange Silicone Gasket$115.88
3263-2300-000000 23 in. 23" Angle Flange Nitrile Gasket$77.22
3263-2400-000005 24 in. 24" Angle Flange Silicone Gasket$123.98
3263-2400-000000 24 in. 24" Angle Flange Nitrile Gasket$82.62
3263-2500-000005 25 in. 25" Angle Flange Silicone Gasket$128.30
3263-2500-000000 25 in. 25" Angle Flange Nitrile Gasket$85.43
3263-2600-000005 26 in. 26" Angle Flange Silicone Gasket$136.51
3263-2600-000000 26 in. 26" Angle Flange Nitrile Gasket$91.04
3263-2700-000000 27 in. 27" Angle Flange Nitrile Gasket$93.96
3263-2700-000005 27 in. 27" Angle Flange Silicone Gasket$140.94
3263-2800-000005 28 in. 28" Angle Flange Silicone Gasket$150.98
3263-2800-000000 28 in. 28" Angle Flange Nitrile Gasket$100.66
3263-2900-000005 29 in. 29" Angle Flange Silicone Gasket$150.98
3263-2900-000000 29 in. 29" Angle Flange Nitrile Gasket$100.66
3263-3000-000005 30 in. 30" Angle Flange Silicone Gasket$153.58
3263-3000-000000 30 in. 30" Angle Flange Nitrile Gasket$102.28
3263-3100-000005 31 in. 31" Angle Flange Silicone Gasket$157.90
3263-3100-000000 31 in. 31" Angle Flange Nitrile Gasket$105.19
3263-3200-000005 32 in. 32" Angle Flange Silicone Gasket$214.81
3263-3200-000000 32 in. 32" Angle Flange Nitrile Gasket$143.10
3263-3300-000005 33 in. 33" Angle Flange Silicone Gasket$220.54
3263-3300-000000 33 in. 33" Angle Flange Nitrile Gasket$146.88
3263-3400-000005 34 in. 34" Angle Flange Silicone Gasket$226.15
3263-3400-000000 34 in. 34" Angle Flange Nitrile Gasket$150.77
3263-3500-000005 35 in. 35" Angle Flange Silicone Gasket$231.55
3263-3500-000000 35 in. 35" Angle Flange Nitrile Gasket$154.44
3263-3600-000005 36 in. 36" Angle Flange Silicone Gasket$237.49
3263-3600-000000 36 in. 36" Angle Flange Nitrile Gasket$158.33
3263-3700-000005 37 in. 37" Angle Flange Silicone Gasket$243.11
3263-3700-000000 37 in. 37" Angle Flange Nitrile Gasket$162.00
3263-3800-000005 38 in. 38" Angle Flange Silicone Gasket$248.72
3263-3800-000000 38 in. 38" Angle Flange Nitrile Gasket$165.78
3263-3900-000005 39 in. 39" Angle Flange Silicone Gasket$254.23
3263-3900-000000 39 in. 39" Angle Flange Nitrile Gasket$169.45
3263-4000-000005 40 in. 40" Angle Flange Silicone Gasket$260.06
3263-4000-000000 40 in. 40" Angle Flange Nitrile Gasket$173.34
